    • MOSFET系列

    新硅能的MOSFET系列产品采用先进的制程结构，兼备了Planar MOSFET，Trench MOSFET，Split-Gate MOSFET 以及Super-Junction等产品系列。具有更好的工艺稳定性和可靠性，以及更快的开关速度、更小的栅电荷和更高的应用效率等优点。产品涵盖12V~900V全系列，可广泛应用于电机驱动、电源等应用领域。

    产品列表
    Part Number   Technology   Package Configuration V(BR)DSS (V) ID (A) VGS (±V) VGS(th) (V) RDSON (mΩ)max Automotive Status
    min max 10V 4.5V 2.5V
    SSF1341UP Trench SOT-23 P -20 -3.5 12 -0.5 -1 40 53 N Production
    ASSF1341 Trench SOT-23 P -12 -3.5 8 -0.4 -1 50 85 Y Sample
    SSF2300UP Trench SOT-23 N 20 3.3 12 0.4 1 30 40 N Production
    ASSF2300UP Trench SOT-23 N 20 3.3 12 0.4 1 30 40 Y Sample
    SSF2300P Trench SOT-23 N 20 3 12 0.4 1 55 80 N Production
    SSF2301UP Trench SOT-23 P -20 -2.6 12 -0.4 -1 75 95 N Production
    ASSF2301UP Trench SOT-23 P -20 -2.6 12 -0.4 -1 75 95 Y Sample
    SSF2301P Trench SOT-23 P -20 -2 12 -0.4 -1 155 210 N Production
    SSF2429UP Trench SOT-23-6 P -20 -5 12 -0.5 -1 35 48 N Production
    SSF2445CU Trench SOT23-6 N+P 20/-20 4.9/-2.9 8/8 0.4/-0.4 1/-1 55/80 75/100 N Production
    SSF2318E-HF Trench SOT-23 N 20 6.5 8 0.4 1 22 30 N Production
    SSF8205VA-HF Trench TSSOP-8 N 20 6 10 0.5 1.2 27.5 37.5 N Production
    SSF8233EJ4-HF Trench DFN2x3-6L N 20 11 12 0.5 1.5 7.2 10.2 N Production
    SSF2341EU Trench SOT-23 P -20 -4 8 -0.3 -0.9 38 48 N Production
    SSF2810EH2-HF Trench TSSOP-8 N 20 8 10 0.4 1 14 18 N Production
    SSF2418E-HF Trench SOT23-6 N 20 6 12 0.5 1 24 33 N Production
    SSF3108H1 Trench SOP-8 N 30 15 20 1 2.5 8 14 N Production
    SSF3108J8 Trench PDFN3x3-8L N 30 22 20 1 2.5 8 14 N Production
    SSF3108J2-HF Trench DFN2x2-6L N 30 18 20 1 2.5 8 14 N Production
    SSF3108H1U Trench SOP-8 N 30 15 20 1 2.5 8 14 N Production
    SSF3108DU Trench TO-252 N 30 40 20 1 2.5 8 14 N Production
    SSF3108J7U Trench PDFN5x6-8L N 30 25 20 1 2.5 10 16 N Production
    SSF3341-HF Trench SOT-23 P -30 -4.2 12 -0.7 -1.3 50 65 120 N Production
    SSF3341UP Trench SOT-23 P -30 -4.2 12 -0.6 -1.3 55 75 N Production
    SSF3115H1 Trench SOP-8 P -30 -10 20 -1 -2.5 15 20 N Production
    SSF3115J7 Trench PDFN5x6-8L P -30 -26 20 -1 -3 14 19 N Production
    SSF3115J8 Trench PDFN3x3-8L P -30 -24 20 -1 -2 14 19 N Production
    SSF3402-HF Trench SOT-23 N 30 5 20 1 2.5 30 48 N Production
    SSF3035L-HF Trench SOT23-3 P -30 -6 20 -1.2 -2.5 30 40 N Production
    SSF3904A Trench TO-263 N 30 120 20 1 3 3.6 5 N Production
    SSF3051G7 Trench SOT23-6 P -30 -4 25 -1 -3 51 85 N Production
    SSF3324-HF Trench SOT-23 N 30 5.8 12 0.7 1.4 34.5 77 N Production
    SSF3006DB Trench TO-252 N 30 90 20 1 3 6 N Production
    SSFT3102 Trench TO-220 N 30 180 20 1 2.5 2.4 5 N Production
    SSF3400K Trench SOT-23 N 30 5.8 12 0.7 1.4 30 33 52 N Production
    SSFN3317-HF Trench DFN3x3-8L P -30 -7 25 -1.7 -3 18 36 N Production
    SSF4013H1 Trench SOP-8 P -40 -13 20 -1 -2.5 15 22 N Production
    SSF4013J7 Trench PDFN5x6-8L P -40 -25 20 -1 -2.5 15 22 N Production
    SSFT4003A Trench TO-263 N 40 200 24 2 4 3.5 N Production
    SSF4013J8 Trench PDFN3x3-8L P -40 -13 20 -1 -2.5 15 22 N Production
    SSFD4031L Trench TO-252 P -40 -40 20 -1 -2.5 18 25 N Production
    SSF4008J7L Trench PDFN5x6-8L N 40 68 20 1.2 2.5 8.5 15 N Production
    SSS4008J8L SGT PDFN3x3-8L N 40 68 20 1.2 2.5 8.5 15 N Production
    SSF4106DL Trench TO-252 N 40 80 20 1 2.5 7.5 12 N Production
    BSS138 Trench SOT-23 N 50 0.22 20 0.5 1.6 3.5 6 N Production
    SSF6007 Trench SOT-23 P -50 -0.13 20 -0.8 -2 7 N Production
    ASSF6014J8X Trench PDFN3x3-8L N 60 33 20 1 3 17 25 Y Sample
    SSF6808D3X Trench TO-252 N 60 80 20 2 4 8 N Production
    SSF6808J73X Trench PDFN5x6-8L N 60 80 20 2 4 8 N Production
    SSF6808A3X Trench TO-263 N 60 80 20 2 4 8 N Production
    2N7002K Trench SOT-23 N 60 0.3 20 1 2.5 3000 3500 N Production
    SSF68083X Trench TO-220 N 60 80 20 2 4 8 N Production
    SSF6670 Trench SOP-8 N 60 3.5 25 1 3 90 120 N Production
    SSF6072G5-HF Trench SOT-223 N 60 4 20 1 2.5 100 115 N Production
    SSF6092G1 Trench SOT-23 N 60 2.7 20 1 2.5 92 N Production
    SSFD6046X Trench TO-252 N 60 20 20 1 2.5 37 48 N Production
    ASSFD6046X Trench TO-252 N 60 20 20 1 3 35 45 Y Sample
    SSFD6035 Trench TO-252 P -60 -26 20 -1 -2.5 40 55 N Production
    SSFD6035U Trench TO-252 P -60 -26 20 -1 -2.5 30 40 N Production
    SSS8504AL SGT TO-263 N 85 120 20 2 4 5.2 N Production
    SSF1090DX Trench TO-252 N 100 10 20 1 2.5 110 140 N Production
    SSS10R20BFU SGT SOP-8 N 100 8 20 1 2.5 20 26 N Production
    SSS10R20DFU SGT TO-252 N 100 30 20 1.4 2.5 20 26 N Production
    SSF13R6 Trench SOT-23 N 100 0.17 20 0.8 2 6 N Production
    SSS1004AL SGT TO-263 N 100 160 20 2.5 4.2 4.8 N Production
    SSS1510J7 SGT PDFN5x6-8L N 150 80 20 3 4.5 10 N Production
    SSF15NS65UEF Super Junction TO-220F N 650 15 30 2.7 3.7 290 N Production
    2N7002K2 Trench SOT-23 N 60 0.27 20 1 2.5 3000 4000 N Production
    2N7002KC Trench SOT-23 N 60 0.3 20 1 2.5 2300 2870 N Production
    BSS138CR Trench SOT-23 N 60 0.3 20 0.5 1.2 2500 4500 N Production
    BSS138C Trench SOT-23 N 60 0.3 20 0.7 1.5 2200 3000 N Production
    SMS004N03A1 SGT TO-220 N 40 140 20 1 2.5 2.3 3.2 N Production
    SMS004N03D1 SGT TO-263 N 40 140 20 1 2.5 2.3 3.2 N Production
    SMS004N8EJ7 SGT PDFN5X6-8L N 40 250 20 1 3 1 1.45 N Production
    SMS006N01J7 SGT PDFN5X6-8L N 60 177 20 1 2.5 2.2 3.2 N Production
    SMS006N01T1 SGT TOLL N 60 360 20 2 4 1.7 N Production
    SMS006N02J7 SGT PDFN5X6-8L N 60 200 20 1 2.5 2.5 3.4 N Production
    SMS006N05J7 SGT PDFN5X6-8L N 60 88 20 1 2.5 6.3 9 N Production
    SMS006N05J8 SGT PDFN3X3-8L N 60 60 20 1 2.5 5.7 8 N Production
    SMS006N09C1 SGT TO-252 N 60 60 20 1 2.5 12 17 N Production
    SMS010N02D1 SGT TO-263 N 100 224 20 2 4 2.4 N Production
    SMS010N03D1 SGT TO-263 N 100 120 20 2.5 3.5 4 N Production
    SMS010N04A1 SGT TO-220 N 100 127 20 2 4 5.5 N Risk
    SMS010N05D1 SGT TO-263 N 100 100 20 1 2.5 5.5 N Production
    SMS010N10J7 SGT PDFN5X6-8L N 100 60 20 1 2.5 13 17 N Production
    SMS015N10J7 SGT PDFN5X6-8L N 150 60 20 2.2 3.8 14.3 N Production
    SSF6014D Trench DPAK N 60 60 20 1 3 14 N Production
    SMT001P13G4 Trench SOT23-3L P -12 -9 12 -0.5 -1 18 25 N Production
    SMT001P14C1 Trench TO-252 P -15 -18 12 -0.4 -1 16.3 22 N Production
    SMT001P14J2 Trench DFN2X2-6L P -12 -11.5 10 -0.5 -1 17.2 26 N Production
    SMT002N13G1E Trench SOT-23 N 20 7.2 10 0.5 1 16 20.7 N Production
    SMT002NA4G1 Trench SOT-23 N 20 1 10 0.4 1 170 247 N Production
    SMT002P02J7 Trench PDFN5X6-8L P -20 -138 12 -0.5 -1 2.2 2.7 N Production
    SMT002P05C1 Trench TO-252 P -20 -60 12 -0.4 -1 6.5 9 N Production
    SMT002P15C1 Trench TO-252 P -20 -17 12 -0.4 -1 20 25 N Production
    SMT002P16G4 Trench SOT23-3L P -20 -9 12 -0.5 -1 21 29 P Production
    SMT002P21G1 Trench SOT-23 P -20 -6 10 -0.5 -1 28 36 N Production
    SMT003N02J7 Trench PDFN5X6-8L N 30 130 20 1 2.5 2 3.2 N Production
    SMT003N03A1 Trench TO-220 N 30 150 20 1 2.2 3.3 4.7 N Production
    SMT003N04J7 Trench PDFN5X6-8L N 30 100 20 1 2.2 3.8 5.2 N Production
    SMT003N05C1 Trench TO-252 N 30 76 20 1 2.5 5 6.8 N Production
    SMT003N06C1 Trench TO-252 N 30 51 20 1 2.5 7.6 11.1 N Production
    SMT003N08C1 Trench TO-252 N 30 42 20 1 2.5 10 13 N Production
    SMT003N10C1 Trench TO-252 N 30 20 20 1 2.2 13 22.5 N Production
    SMT003P02J7 Trench PDFN5X6-8L P -30 -131 20 -1 -2.5 2.5 3.6 N Production
    SMT003P03J7 Trench PDFN5X6-8L P -30 -99 20 -1 -2.5 3.7 6.1 N Production
    SMT003P06J8 Trench PDFN3X3-8L P -30 -54 20 -1 -2.5 7 11.6 N Production
    SMT003P08C1 Trench TO-252 P -30 -40 20 -1.4 -2.4 10.5 14 N Production
    SMT003P10H1 Trench SOP-8 P -30 -12.5 20 -1 -2.5 13.4 18.7 N Production
    SMT003P18H1 Trench SOP-8 P -30 -8 20 -0.7 -1.5 23.4 30 N Production
    SMT003P20C1 Trench TO-252 P -30 -15 20 -1.4 -2.4 25 36 N Production
    SMT003P20H1 Trench SOP-8 P -30 -7.8 20 -1 -2.5 25 41 N Production
    SMT003P26G4 Trench SOT23-3L P -30 -5.8 20 -0.7 -1.5 34 44.8 N Production
    SMT003P51G1 Trench SOT-23 P -30 -3.3 20 -1 -2 65 90 N Risk
    SMT003P58G1 Trench SOT-23 P -30 -4 12 -0.6 -1.3 68 80 N Production
    SMT004N02J7 Trench PDFN5X6-8L N 40 107 20 1 2.5 2.9 4.4 N Production
    SMT004N04C1 Trench TO-252 N 40 96 20 1 2.5 5.1 6.6 N Risk
    SMT004N05J7 Trench PDFN5X6-8L N 40 57 20 1 2.5 5.9 10.6 N Production
    SMT004N06C1 Trench TO-252 N 40 57 20 1 2.5 10.3 N Production
    SMT004N10C1 Trench TO-252 N 40 36 20 1 2.5 20 N Production
    SMT004N13C1 Trench TO-252 N 40 32 20 1 2 17 20 N Production
    SMT004N19H1 Trench SOP-8 N 40 6.3 20 1 2.5 26 33 N Production
    SMT004P04J7 Trench PDFN5X6-8L P -40 -78 20 -1 -2.5 5.6 7.8 N Production
    SMT004P09C1 Trench TO-252 P -40 -57 20 -1 -2.5 13.2 18.2 N Production
    SMT004P40H1 Trench SOP-8 P -40 -4.2 20 -1 -2.5 60 78 N Production
    SMT004P30C1 Trench TO-252 P -40 -24 20 -1 -2.5 39 54.5 N Production
    SMT006N07A1 Trench TO-220 N 60 72 20 1 2.5 9.1 11 N Production
    SMT006N08C1 Trench TO-252 N 60 58 20 1 2.5 9.1 11.1 N Production
    SMT006N10C1 Trench TO-252 N 60 55 20 2.2 3.8 11.7 N Production
    SMT006N11C1 Trench TO-252 N 60 50 20 2 4 15 N Production
    SMT006N12C1 Trench TO-252 N 60 50 20 1 2.5 15 21 N Production
    SMT006N26C1 Trench TO-252 N 60 21 20 1 2.5 35 43 N Risk
    SMT006N80G1 Trench SOT-23 N 60 3 20 1 2 100 110 N Production
    SMT006P26A1 Trench TO-220 P -60 -34 20 -1 -2.5 34 42 N Production
    SMT006P88G1 Trench SOT-23 P -60 -5 20 -1 -2.5 120 145 N Production
    SMT007N07A1 Trench TO-220 N 68 80 20 2 4 9.5 N Production
    SMT008N08A1 Trench TO-220 N 80 90 20 2 4 8.7 N Production
    SMT010N18A1 Trench TO-220 N 100 40 20 2 4 24 N Production
    SMT010N37C1 Trench TO-252 N 100 20 20 1 2.5 48 55 N Production
    SMT010NB2G1 Trench SOT-23 N 100 3 20 1 2.5 286 325 N Production
    SMT015PB7H1 Trench SOP-8 P -150 -2 20 -2 -4 345 N Production
    SMT020PF4D1 Trench TO-263 P -200 -6 20 -2 -4 834 N Production
    SSF2301A Trench SOT-23 P -20 -4 12 -0.5 -1 65 80 N Production
    SSF3108H1X Trench SOP-8 N 30 15 20 1 2.5 6.5 9.8 N Production
    SSFD4004 Trench TO-252 N 40 145 20 1 3 3.2 N Production
    SMS010N02T1 SGT TOLL N 100 224 20 2 4 3 N Production
    SMS010N06D1 SGT TO-263 N 100 140 20 2 4 6 N Production
    SMS015N06D1 SGT TO-263 N 150 150 20 2 4 6 N Production
    SMS015N07A1 SGT TO-220 N 150 240 20 1 2.5 5.8 N Production
    SMS015N07D1 SGT TO-263 N 150 240 20 1 2.5 5.8 N Production
    SMS015N12D1 SGT TO-263 N 150 85 20 2.5 3.5 12 N Production
    SMT004N03T1 Trench TOLL N 40 180 20 2 4 3 N Production
    SMT008N09C1 Trench TO-252 N 80 80 20 2 4 9 N Production
    SSF7N60CFL Trench TO-220F N 600 7A 30 2 4 1350 N Production
    SSF10N60CFL Trench TO-220F 650 10A 30 2 4 800 N Production
    SSF3006DBC Trench TO-252 N 30 100 20 1 2.5 6 N Production
    SSF6035H1 Trench SOP-8 P -60 -9 20 -1 -2.5 43 N Production
    SSF6808D4X Trench TO-252 N 60 80 20 2 4 8 N Production
    SSF6808D5X Trench TO-252 N 68 80 20 2 4 N Production
    SSS1004L SGT TO-220 N 100 160 20 2.5 4.2 4.8 N Production
    SSS8504DL SGT TO-252 N 85 120 20 2 4 5.2 N Production
    SSFD3005 Trench TO-252 P -30 -85 25 -1.5 -3.5 7.5 N Production
    SMT004N03J7 Trench PDFN5X6-8L N 40 180 20 2 4 2.4 N Production
    SMT004N03A1 Trench TO-220 N 40 172 20 2 4 2.4 N Production
    SMT004N03D1 Trench TO-220 N 40 170 20 2 4 2.4 N Production
